Compact Light Sets from Eurolite are the practical lighting solution for solo entertainers, mobile DJs and restaurants!
OPIS:
Four spots on a bar provide good basic lighting, while additional effects spread party mood. With the KLS NEXT FX, in addition to four spots, two mushroom effects are installed on the bar. Four UV LEDs in the bar provide the popular black light effect. In addition, a class 2 show laser is on board.
Bar with powerful spots, UV strobe LEDs, laser (RG, 2M), QuickDMX port and carrying bag
DMX light effect bar with laser, 2 rotating LED mushrooms, 4 LED spots and UV strobe LEDs
2 laser diodes project hundreds of red and green laser beams
2 rotating mushrooms with four bright LEDs (red, green, blue and warm white) each
4 spots with four high-power RGB/WW LEDs (4in1) each
4 UV strobe LEDs
Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
Ultra-light, ideally suited for mobile use
Crossbar with integrated DMX control unit and TV spigot for tripod installation
2 swivel mounting brackets
Comes pre-assembled with practical transport bag
Convenient control via included IR remote control or optional wireless foot switch
LED mushrooms and LED spots individually tiltable and controllable
Spots with 7° beam angle
Auto, music, master/slave and DMX mode
Brand-new software design with smart programs
26 built-in auto and music show programs that include all 4 effect units
Control panel with LED display for easy configuration
Brightness adjustable via rotary dial
Supports QuickDMX - the wireless DMX system from Eurolite
Built-in phantom-powered USB port for QuickDMX, CRMX and WDMX receivers (optional)
When fog is used, this effect becomes especially attractive
Mains input and output for power linking up to 8 units
LED: Spot 3 x high-power 4 W 4in1 QCL RGB/WW (homogenous color mix)
LED: Multi beam effect 4 x high-power 3 W R/G/B/WW
LED: Strobe effect 4 x high-power 1,5 W ultra violet (UV)
Can be operated in 6; 8; 11; 21; 25; 29 CH mode
The device is cooled by cooling fan
Controlling by QuickDMX via USB (optional); DMX; stand-alone; Sound to light via Microphone; IR remote control; Wireless footswitch (optional)
Preprogrammed in Light Captain
Effect: Laser; UV effect; multi beam effect
For application areas such as: Wedding/gala
TEHNIČKE SPECIFIKACIJE:
Power supply:100-240 V AC, 50/60 Hz
Power consumption:90 W
IP classification:IP20
Protection class:Class I
Power connection:Mains input P-Con (blue), mounting version power supply cord with safety plug (provided)
Cable construction:3 x 1,0 mm² H05VV-F
Cable length:3 m
Power output:1 x P-Con (gray), mounting version
Fuse:T 1 A Fuse replaceable
Lamp type:LED lamp
LED:Spot 3 x high-power 4 W 4in1 QCL RGB/WW (homogenous color mix)
Multi beam effect 4 x high-power 3 W R/G/B/WW
Strobe effect 4 x high-power 1,5 W ultra violet (UV)
Flash rate:0 - 30 Hz
DMX channels:6; 8; 11; 21; 25; 29
DMX input:1 x 3-pin XLR (M) mounting version
DMX output:1 x 3-pin XLR (F) mounting version
Cooling:Cooling fan
Control:QuickDMX via USB (optional); DMX; stand-alone; Sound to light via Microphone; IR remote control; Wireless footswitch (optional); Light Captain
Beam angle:7°
Beam angle (1/2 peak):Spot 7°
Beam angle (1/10 peak):Spot 20°
Housing color:Black
Attachment system:TV spigot Ø 28mm
Dimensions:Width: 1,11 m
Depth: 15 cm
Height: 41 cm
Weight:10,50 kg
Noise classification:Class 2 (slight noise)
Laser
Laser class:Class 2M
Laser color:R/G
Laser module:Red (R) 100 mW 650nm
Green (G) 30 mW 532nm
Remote control
Battery:Button cell 3.0 V CR2025 lithium manganese built-in
