Maverick MK3 Wash podiže ljestvicu za output, dosljednost boja i pixel efekte. Pokreće ga 27 (40 W) Osram RGBW LED dioda, ima snagu da se nosi s bilo kojom primjenom uključujući long throw rad. Pixel-mapping efekti ugrađeni u makronaredbe boja i gobosa, zajedno s opcijom CTO color-mixinga čine ovaj uređaj kompletnim wash rješenjem. Opcije upravljanja uključuju DMX, sACN, Art-Net, Kling-Net, W-DMX ili RDM.

AT A GLANCE

• Fully featured RGBW LED yoke wash fixture with pixel mapping and zoom
• 16-bit dimming of master dimmer as well as individual colors for smooth control of fades
• Built in colors for quick design possibilities
• Built in virtual gobo wheel with background colors for impressive atmospheric effects
• Precise movement of pan, tilt, and zoom
• Quiet operation for a wide range of installation situations
• DMX, WDMX, S ACN, Art-Net, and Kling-Net control for full flexibility
• RDM Enabled for remote addressing and trouble shooting
• 5.2° - 65.1° Zoom range for variable beam sizes
• True 1 compatible power input
• Battery backup touchscreen display with auto rotate depending on fixture orientation

SPECIFICATIONS

OPTICAL

• Light Source: 27 LEDs (quad-color RGBW) 40 W, (2.6A), 50,000 hours life expectancy
• Color Temperature (range): 2800 to 10000 K
• Beam Angle: 5° to 36°
• Field Angle: 7.4° to 52.8°
• Cutoff Angle: 8.6° to 65.1°
• Zoom Range: 5.2° to 65.1°
• Lumens - Source: 18,000
• Lumens - Output: 13,300
• Illuminance (7.4°): 60,090 lux @ 5 m
• Illuminance (45°): 2,040 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz

DYNAMIC EFFECTS

• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 20 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Move-in-Black: Yes
• Dim Curves: 4

CONSTRUCTION / PHYSICAL

• Dimensions: 18.7 x 11.49 x 22.93in 459 x 292 x583 mm)
• Weight: 68.2 lb (31 kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant polymer

CONNECTIONS

• Power Connection: Edison plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

CONTROL

• Control Protocol: Art-Net, Kling-Net, sACN, DMX, W-DMX, RDM
• DMX Channels Single Mode: 20, 129, 243 or 297
• DMX Channels Dual Mode – Function: 9,21,27
• DMX Channels Dual Mode – Pixel: 81,108,216
• Art-Net Channels Single Mode: 21, 129, 243 or 297
• Art-Net Channels Dual Mode – Function: 9,21,27
• Art-Net Channels Dual Mode – Pixel: 81,108,216

ELECTRICAL

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 1,120 W, 9.54 A @ 120 V, 60 Hz
• Power and Current: 1,090 W, 5.35 A @ 208 V, 60 Hz
• Power and Current: 1,120 W, 4.79 A @ 230 V, 50 Hz

CERTIFICATIONS / QUALIFICATIONS

• CE, MET, FCC
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

WHAT'S INCLUDED

• Seetronic Powerkon IP65 power cord
• Omega bracket with mounting hardware

OPTIONAL ACCESSORIES

• Professional Clamp: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• DMX Cables
